BrightBox Osiris Curve 2.9 | 2.9mm Curved LED Panel | Mobile Video Wall with Front/Rear Service

Curved Mobile LED Video Wall Panel

The BrightBox Osiris Curve 2.9 is a flexible, mobile-ready LED video wall panel that combines a curved design with crisp 2.9mm pixel pitch and vibrant output. Designed for events, exhibitions, and high-impact installations, this panel features corner protection, swappable power boxes, and both front and rear serviceability—making it a professional-grade solution for dynamic visual environments.

BrightBox Osiris Curve 2.9 Competitive Differences

• ±5° adjustable curvature for concave or convex screen configurations
• Swappable all-in-one power box and dual access design for easy maintenance

BrightBox Osiris Curve 2.9 Description

The BrightBox Osiris Curve 2.9 delivers stunning visuals and installation flexibility for live productions, trade shows, and mobile video wall applications. With a fine 2.9mm pixel pitch and 168 x 168 resolution per panel, it delivers sharp, detailed images suitable for mid-range viewing distances. Built with black SMD1515 LEDs, this panel produces high-contrast visuals with 800-nit brightness—ideal for indoor event spaces. The curved design enables both convex and concave configurations (±5°), making it perfect for immersive screen setups and creative layouts. Whether used as a backdrop, main display, or part of a modular design, the Osiris Curve 2.9 ensures impactful audience engagement. The panel includes a swappable all-in-one power box for quick servicing and is front and rear serviceable, allowing technicians easy access regardless of mounting conditions. It’s also engineered with corner protection for safe handling and transport. Certified for CE, ROHS, and FCC standards and backed by a 3-year warranty, this panel is purpose-built for professional use.

Model Features

• 2.9mm pixel pitch with curved ±5° flexibility
• 168 x 168 pixel resolution per panel
• 800 nit brightness for vibrant indoor displays
• Swappable all-in-one power box for fast servicing
• Corner protection for safe transport and setup
• Front and rear serviceable design
• Novastar control system compatibility
• Certified: CE, RoHS, FCC

Model Specifications

• Pixel Pitch: 2.9 mm
• LED Type: Black SMD1515
• Pixel Resolution: 168 x 168
• Panel Dimensions: 19.7″ x 19.7″ x 3.3″ (500 x 500 x 83 mm)
• Weight: 17.6 lb (8 kg)
• Brightness: 800 Nit
• Grayscale: 16-bit
• Scan Mode: 1/28
• Pixel Density: 112,896 dots/m²
• Refresh Rate: ≥3,840 Hz
• Max Power Usage: 150W
• Input Power: 450W
• Lifespan: 100,000 hours
• IP Rating: IP30 (Front), IP20 (Rear)
• Serviceability: Front and Rear
• Control System: Novastar
• Warranty: 3 Years
• Case Pack: 9 Panels Per Flight Case
