10-Port DMX Node with LTC, MIDI & 10Scene Support

ChamSys GeNetix GN10 is a high-capacity, rack-mountable DMX distribution node with 10 configurable RDM-capable DMX ports, built for flexible data routing over Ethernet or USB. Designed for integration with ChamSys MagicQ systems, it supports advanced control protocols including Art-Net, sACN, and ChamNet, and features built-in timecode and MIDI capabilities.

ChamSys GeNetix GN10 Competitive Differences

10 configurable DMX ports with input/output and RDM support
Full MagicQ PC unlock via USB or dual-network connection

ChamSys GeNetix GN10 Description

The ChamSys GeNetix GN10 is a powerful solution for remote lighting data distribution across large-scale productions, permanent installations, and touring systems. It features 10 DMX ports that can be independently configured as input or output, all with RDM support, making it highly adaptable to complex lighting network needs. With dual network ports and support for PoE or mains power via powerCON TRUE1, the GN10 is engineered for redundancy and reliability. Onboard LTC and MIDI ports allow precise timecode synchronization and MIDI communication over Ethernet, making it ideal for show-critical applications involving remote media control, timecoded events, and cue recall. When connected via USB, the GN10 fully unlocks ChamSys MagicQ PC software, providing complete functionality on Mac, Linux, or Windows. Used over network, it can unlock up to two MagicQ instances, offering scalable expansion for lighting control systems. The GN10 can be configured locally via its onboard display and encoder, or remotely using its integrated web server. Mounting options include M12 rigging, DIN rail installation, or optional rack ears for 19” rack mounting, making the GN10 ready for any professional environment.

Model Features

10 DMX ports with RDM support, configurable as input or output
Supports Art-Net, sACN, and ChamNet protocols
LTC and MIDI timecode and notes over Ethernet
USB connection enables full MagicQ software unlock
Network unlock for up to 2 MagicQ instances
Dual network ports with PoE on Port 1
Web-based and onboard configuration with display
Configurable DMX timings and DMX redundancy support
Mount via M12 receiver, optional rack ears, or DIN rail

Model Specifications

DMX Ports: 10x 5-pin XLR (RDM capable, configurable I/O)
Network Ports: 2 (PoE support)
LTC & MIDI Ports: Yes (via Ethernet and physical I/O)
Protocols Supported: Art-Net, sACN, ChamNet
Power Input: Neutrik powerCON TRUE1 (AC 110–240V)
Dimensions: 18.9 x 8.6 x 1.8 in (48.0 x 21.8 x 4.5 cm)
Weight: 6.06 lb (2.75 kg)
PoE Support: Yes (Port 1)

What's In The Box

ChamSys GeNetix GN10 Node
Neutrik powerCON TRUE1 Power Cable
