Chauvet Pro COLORado Batten 72X | 72x3W RGBWA LEDs - IP65 | Outdoor Wash Light with Smooth 16-Bit Dimming

Chauvet Pro COLORado Batten 72X | 72x3W RGBWA LEDs - IP65 | Outdoor Wash Light with Smooth 16-Bit Dimming

$1,403.00

Order within [hour] to get by [date_end]

Quantity

Direct Ship from Our Supplier

Guarantee Safe
Checkout

trust_2dea69ed-7223-44f3-828d-a80bc0f3aef4

IP65 LED Batten Wash Light

Chauvet Pro COLORado Batten 72X is a tour-grade, IP65-rated batten-style fixture equipped with 72 calibrated 3W RGBWA LEDs for stunning color washes in any environment. Designed for versatility and durability, it delivers exceptional color rendering and smooth dimming, making it ideal for concerts, broadcast, theatre, and outdoor installations.

Chauvet Pro COLORado Batten 72X Competitive Differences

72 calibrated RGBWA LEDs for rich, even washes across the spectrum
IP65 rating with all-weather power and DMX connections for outdoor use

Chauvet Pro COLORado Batten 72X Description

The Chauvet Pro COLORado Batten 72X is built to thrive in demanding production environments—indoors or outdoors. Featuring 72 high-efficiency RGBWA LEDs (3W each), it produces vibrant colors, natural whites, and subtle pastels, all with excellent uniformity. Its native 24° optics provide a balanced beam, with horizontal and vertical field angles of 39° and 34°, respectively. This fixture supports advanced 16-bit dimming with five dimming curves for smooth fades, even when replacing aging conventional rigs. Selectable PWM frequencies up to 25,000 Hz ensure flicker-free operation for on-camera use. With built-in color temperature presets from 3200K to 10000K and customizable color mixing, it fits easily into a variety of lighting designs. The COLORado Batten 72X includes a large, password-protected display, rugged aluminum housing, and IP65-rated connectors for true all-weather reliability. It ships with dual Omega brackets for flexible mounting in horizontal or vertical orientations. Whether on a touring rig, architectural install, or festival stage, this batten delivers consistent performance with minimal setup time.

Model Features

72x 3W RGBWA LEDs (18 red, 18 green, 18 blue, 9 white, 9 amber)
IP65-rated for temporary outdoor or wet-use environments
Color temperature range: 3200K to 10000K
Beam angle: 24° | Field angle: H: 39°, V: 34°
16-bit dimming with 5 selectable dimming curves
Selectable PWM frequencies up to 25,000 Hz
18 DMX personalities from 3 to 43 channels for full control flexibility
Built-in automated and user-customizable programs

Model Specifications

Lumens: 3,631
Illuminance: 1730 lux @ 5m (total)
Dimensions: 39.37 x 6.14 x 2.95 in (1000 x 156 x 75 mm)
Weight: 18.6 lb (8.4 kg)
Power: 100–240V AC | Max Draw: 164W @ 208V
IP Rating: IP65 (outdoor-rated)

What's In The Box

COLORado Batten 72X fixture
Seetronic Powerkon IP65 power cord
2x Omega brackets with mounting hardware
