Shure SLXD5-G58 | Digital Camera-Mount Wireless Microphone Receiver (G58: 470 to 514 MHz)

Shure SLXD5 Camera-Mount Digital Wireless Receiver

Designed to meet the needs of today's videographers, journalists, documentary makers, and content producers, the Shure SLXD5 is a camera-mount digital wireless microphone receiver that delivers crystal-clear sound quality and is quick and easy to set up, even if you're using multiple systems on set. Compatible with the SLXD1 bodypack, SLXD2 handheld, and SLXD3 plug-on transmitters, the versatile single-channel receiver includes a cold-shoe mount for your camera and also fits perfectly into an audio bag. The comprehensive feature set ensures reliable wireless transmission and professional-sounding, broadcast-ready results for demanding filmmakers and creators.

Transparent Digital Sound, Dependable Performance, and Multi-Mic Mode

• 24-bit digital audio with a 20 Hz to 20 kHz frequency response and 118 dB dynamic range
• Operates in the G58: 470 to 514 MHz UHF band with 44 MHz tuning range and 1760 frequencies
• Digital Predictive Switching Diversity to prevent dropouts
• Low latency of 3.2 ms for easy synchronization
• Supports up to 32 mics simultaneously
• Multi-Mic Mode for efficient channel allocation

A Rugged Receiver Ready for the Camera or Audio Bag

• Compact, user-configurable with a bright OLED screen
• Metal chassis with adjustable front-mounted antennas
• Adjustable gain control and dual 3.5mm outputs for headphone monitor and switchable line/mic output
• Automatic frequency scanning and IR sync
• Operates up to 5.5 hours on two AA batteries or SB903 rechargeable battery
• USB-C port for recharging the SB903 battery or powering the unit

Optional Rechargeable Battery Management

• SB903 lithium-ion rechargeable battery with single, dual-docking, or 8-bay chargers available
• Displays remaining battery life in hours and minutes when powered by SB903
• USB-C port for battery recharging and direct powering

A Variety of Mics and Transmitters Available

• SLXD1 bodypack transmitter with TA4M connector for lavalier and headset microphones
• WL183 omnidirectional lavalier mic
• WL184 supercardioid lavalier mic
• UL4 UniPlex subminiature cardioid lav
• DL4 DuraPlex miniature lavalier with IP57 rating
• SLXD2 handheld transmitter with various mic capsules
• SLXD3 plug-on transmitter for XLR microphones with 12 and 48V phantom power

Key Features

• Use with SLX-D Wireless Transmitters
• 1-Channel Receiver for Camera or Bag Use
• 118 dB Dynamic Range, 24-Bit Audio
• Reliable Predictive-Diversity Antennas
• 44 MHz Bandwidth, 1760 Frequencies
• Multi-Mic Mode for Complex Setups
• Easy-to-Read OLED Screen
• 5.5 Hours on Two AA or SB903 Battery
• Expandable to 32 Mic Channels/330' Range

Shure SLXD5 Specs

• Wireless Technology: Digital UHF
• Diversity: True Digital Diversity
• Max Operating Range: 328' / 100 m
• Receiver Type: Camera-Mount
• Number of Audio Channels: 1
• Audio I/O: 1x 1/8" / 3.5 mm TRS Female Balanced Mic/Line Output, 1x 1/8" / 3.5 mm TRS Female Unbalanced Headphone Output
• Power Requirements: Battery, Bus Power (USB)
• Number of RF Channel Frequencies: 1760
• RF Frequency Band: G58: 470 to 514 MHz
• RF Bandwidth: 44 MHz
• Frequency Step Size: 25 kHz
• RF Channel Scanning: Auto-Scan
• Max Transmitters per Band: 32
• Latency: 3.2 ms
• THD: <0.02%

Receiver

• Receiver Type: Camera-Mount
• Mounting Options: Shoe-Mount (with Included Hardware)
• Antenna: 2x 1/4 Wave Flexible Whip, Fixed (Front-Mount)
• Number of Audio Channels: 1
• Audio I/O: 1x 1/8" / 3.5 mm TRS Female Balanced Mic/Line Output, 1x 1/8" / 3.5 mm TRS Female Unbalanced Headphone Output
• Gain Range: -18 to +42 dB
• Audio Output Level: 1/8" / 3.5 mm Output: +15 dB (Line Level, Balanced)
• Phantom Power Protection: No
• Frequency Response: 20 Hz to 20 kHz +1/-2 dB (Dependent on Mic)
• USB/Lightning Connectivity: 1x USB-C Female (Bus Power, Charging)
• Impedance: 1/8" / 3.5 mm Output: 450 Ohms (Balanced)
• Approximate RF Sensitivity: -97 dBm
• Spurious Rejection: >75 dB
• Power Requirements: Battery, Bus Power (USB)
• Battery Type: 2x AA, 1x Shure SB903
• Approx. Battery Life: 5.5 Hours
• Display & Indicators: OLED (AF Level, Battery Status, Channel, Frequency, Group, Menu Navigation, Metering, Multifunction, Output Level, RF Level, Sync, Transmitter Battery Status)
• Housing: Aluminum
• Operating Temperature: 0 to 122°F / -17 to 50°C
• Storage Temperature: -20 to 165°F / -28 to 73°C
• Dimensions: 2.7 x 4.2 x 1" / 68 x 107 x 25.3 mm
• Weight: 0.4 lb / 182 g

In the Box

• 1 SLXD5 Camera-Mount Digital Wireless Receiver
• 1 Zippered Carrying Pouch
• 2 AA Alkaline Batteries
