Ashly KLR-3200 | 650W Stereo Power Amplifier with Class-AB Circuitry

High-Powered Stereo Amplifier for Professional Audio Applications

The Ashly KLR-3200 is a professional-grade stereo power amplifier engineered for superior audio performance and versatility. With its robust power output, efficient Class-AB circuitry, and flexible connectivity, the KLR-3200 is ideal for demanding sound reinforcement applications. This compact 2RU rackmount amplifier offers reliable performance, intuitive controls, and advanced protection, ensuring consistent results in any professional audio setup.

Ashly KLR-3200 Competitive Differences

• Delivers 650W per channel at 8 ohms stereo, up to 3200W in bridged mono mode
• Class-AB circuitry for efficient and high-fidelity audio
• Switchable stereo, bridged, and parallel modes for versatile configurations
• Euroblock and combo XLR/TRS inputs with Neutrik Speakon outputs for seamless connectivity
• 3-position gain and high-pass filter switches for tailored sound control
• Switchable limiter to prevent distortion during high-output operation
• Forced air cooling with front-to-rear airflow and removable dust filters
• Integrated protection circuitry to guard against over-current, DC output, and overheating
• Front panel level controls and LED indicators for easy monitoring

Ashly KLR-3200 Description

The Ashly KLR-3200 offers the perfect balance of power, efficiency, and durability, making it a trusted choice for professional audio systems. Its robust power output delivers crisp highs, punchy midrange, and deep bass, while the Class-AB circuitry ensures optimal performance. The amplifier’s switchable modes—stereo, bridged, and parallel—accommodate a wide range of system configurations. Designed with convenience in mind, the KLR-3200 features front panel level controls, LED status indicators, and flexible input/output connectivity options. Its switch mode power supply and efficient cooling system ensure reliable operation in even the most demanding conditions. For installers and sound engineers seeking a reliable and high-performing amplifier, the KLR-3200 is a powerful solution.

KLR-3200 Features

• Power output:
  • 650W per channel @ 8 ohms stereo
  • 1100W per channel @ 4 ohms stereo
  • 1600W per channel @ 2 ohms stereo
  • 3200W @ 4 ohms bridged mono
• Class-AB circuitry for efficient and reliable performance
• Inputs: 2 x Euroblock, 2 x XLR/TRS combo
• Outputs: 2 x Neutrik Speakon
• Front panel controls for levels, gain, and high-pass filters
• LED indicators for level, clip/protect, and power
• Integrated protection circuitry for safe operation
• Forced air cooling with removable dust filters

KLR-3200 Specifications

• Frequency Response: 20Hz - 20kHz
• Damping Factor: >380
• Signal-to-Noise Ratio: >109dB
• Total Harmonic Distortion (THD): <0.05%
• Power Consumption: 0.92A (idle)
• Dimensions: 19 x 3.5 x 16" (482 x 88 x 407mm)
• Weight: 24 lbs (10.9kg)
• Package Weight: 33.55 lbs
• Box Dimensions: 22.9 x 21.9 x 6.3"
