Dante Expansion Card

Behringer WING-DANTE is a Dante audio networking expansion card designed to integrate the WING console into Dante-based audio-over-IP systems. It enables high-channel-count digital audio transmission over standard network infrastructure, making it ideal for live sound, broadcast, installed systems, and recording applications.

Behringer WING-DANTE Competitive Differences

64x64-channel bi-directional Dante interface for high-capacity audio networking
Dual EtherCON ports with redundant network capability for reliable operation

Behringer WING-DANTE Description

The Behringer WING-DANTE expansion card adds powerful Dante audio-over-IP functionality to the WING digital mixing console. With support for 64 channels of bi-directional audio at 48 kHz, it allows engineers to seamlessly connect to a wide range of Dante-enabled devices including stageboxes, amplifiers, and recording systems.

Designed for low-latency, high-resolution performance, the card transmits 24-bit digital audio with sample-accurate synchronization across the network. It integrates easily into existing 100 Mbit/s or Gigabit Ethernet infrastructures, with DSCP-based QoS ensuring stable performance even in complex network environments.

Flexible routing and configuration are handled via the Dante Controller software, allowing full control over signal paths between connected devices. The system also supports Dante Virtual Soundcard, enabling multitrack recording and playback directly to a computer over Ethernet, making it a powerful solution for both live production and studio workflows.

For mission-critical applications, the dual EtherCON ports can be configured for redundant operation, ensuring uninterrupted audio transmission in case of network failure. Additionally, the integrated Ethernet switch supports remote control of the WING console, simplifying system setup and control in distributed environments.

WING-DANTE Features

64-channel, 48 kHz bi-directional Dante audio interface
24-bit audio with low-latency, sample-accurate synchronization
Compatible with standard 100 Mbit/s and Gigabit Ethernet networks
DSCP-based QoS for optimized network performance
Supports mixed sample rates and bit depths within Dante networks
Dual EtherCON ports for primary and secondary (redundant) connections
Integration with Dante Controller software for routing and configuration
Compatible with Dante Virtual Soundcard for multitrack recording and playback
Integrated Ethernet switch enables remote control of WING console

WING-DANTE Specifications

Product Type: Dante Expansion Card
Compatibility: Behringer WING
Channels: 64 x 64 (bi-directional)
Sample Rate: 48 kHz
Bit Depth: 24-bit
Data I/O: 2 x EtherCON (Primary, Secondary)
