BrightBox Osiris Curve 2.6 | 2.6mm Curved LED Panel | Mobile Video Wall with 800 Nit & Dual Service Access

Curved Mobile LED Video Wall Panel

The BrightBox Osiris Curve 2.6 is a high-performance LED panel designed for mobile and event-based video wall systems. With a sharp 2.6mm pixel pitch and ±5° curve capability, it delivers immersive visuals while supporting creative display configurations. Lightweight and rugged, this panel is built to withstand repeated transport and setup while maintaining exceptional image quality.

BrightBox Osiris Curve 2.6 Competitive Differences

• ±5° concave/convex curvature for creative visual designs
• Swappable all-in-one power box and dual (front/rear) serviceability

BrightBox Osiris Curve 2.6 Description

The BrightBox Osiris Curve 2.6 delivers professional-grade visuals for live events, exhibitions, and mobile installations. Featuring a tight 2.6mm pixel pitch and high 192 x 192 resolution per panel, it provides clear, detailed video performance for mid-range viewing applications. The curved ±5° design supports both convex and concave layouts, opening the door for immersive video wall creativity. Each panel features black SMD1515 LEDs, delivering 800 nit brightness and excellent contrast, while a refresh rate of ≥3,840 Hz ensures flicker-free playback even under video cameras or fast-moving content. Engineered for touring use, it includes corner protection and a swappable all-in-one power box for rapid on-site servicing. With both front and rear service access, setup and maintenance are streamlined, and its compact 500 x 500 mm footprint allows for tight packing and efficient storage in mobile flight cases. Certified to ETL, FCC, ROHS, and CE standards, the Osiris Curve 2.6 is a smart choice for AV professionals and rental houses.

Model Features

• 2.6mm pixel pitch for sharp indoor visuals
• 192 x 192 resolution per panel
• ±5° curve design for flexible concave/convex layouts
• 800 nit brightness for vivid event visuals
• Swappable all-in-one power box for fast servicing
• Corner protection for mobile/touring use
• Front and rear serviceable
• Certified: ETL, FCC, ROHS, CE

Model Specifications

• Pixel Pitch: 2.6 mm
• LED Type: Black SMD1515
• Pixel Resolution: 192 x 192
• Panel Dimensions: 19.6″ x 19.6″ x 3.3″ (500 x 500 x 83 mm)
• Weight: 17.6 lb (8 kg)
• Brightness: 800 Nit
• Refresh Rate: ≥3,840 Hz
• Grayscale: 16-bit
• IP Rating: IP30 (Front), IP20 (Rear)
• Serviceability: Front and Rear
• Control System: Novastar
• Warranty: 3 Years
• UPC: 618528598543
