Chauvet Pro Ovation CYC 3 FC | 1m RGBAL Cyclorama Wash | Silent Operation with Glare Shield & Footlight Mode

RGBAL Cyclorama Wash Light

The Chauvet Pro Ovation CYC 3 FC is a low-profile, convection-cooled cyclorama fixture designed for seamless stage washes or discreet footlight applications. With 180 RGBAL LEDs and 19,575 lumens of output, it produces an exceptionally flat, even field of rich, saturated colors and tunable whites—ideal for theatre, broadcast, or film. Its silent operation, high CRI, and modular 1-meter form factor make it an essential fixture for immersive scenic lighting.

Chauvet Pro Ovation CYC 3 FC Competitive Differences

• 1-meter RGBAL cyc/footlight with 19,575 lumens and 111° beam angle
• Completely fanless design for silent operation in sound-critical environments

Chauvet Pro Ovation CYC 3 FC Description

The Ovation CYC 3 FC delivers powerful and beautifully blended lighting for stage backdrops and footlight positions, in a low-profile 1-meter format. Matching perfectly with the shorter CYC 1 FC, this fixture offers consistent output and beam uniformity across extended configurations, ensuring uninterrupted color fields for theatrical and production environments. Featuring a full RGBAL color engine (Red, Green, Blue, Amber, Lime), the CYC 3 FC allows precise color rendering and subtle pastel tones along with bold primaries. Color temperature presets (2800K–6500K) and a virtual gel library make it easy to match any existing rig or scenic requirement. The 16-bit dimming on all channels and selectable PWM rates up to 25,000 Hz make it perfect for on-camera work without flicker or dimming artifacts. The integrated kickstand and adjustable glare shield give users direct control over throw shape and coverage, while included omega brackets allow for secure mounting on stage decks or pipe structures. With an IP20 rating and fully convection-cooled housing, the CYC 3 FC is ideal for indoor venues where performance and silence are non-negotiable.

Model Features

• RGBAL LED engine with 180 LEDs (36 per color)
• Flat, even color field with 111° beam and 151° field angle
• Color temperature presets from 2800K to 6500K
• Virtual color wheel with gel-matched colors
• 16-bit dimming with 4 selectable curves
• Adjustable glare shield and integrated kickstands
• Selectable PWM (600–25,000 Hz) for flicker-free camera use
• DMX and RDM control with 11 user-selectable modes
• Silent convection cooling—no fans

Model Specifications

• Light Source: 180 RGBAL LEDs (2.5W–3.5W each)
• Lumens: 19,575 lm
• CRI: 90 @ 3200K
• Beam Angle: 111.4° H x 76.7° V
• Field Angle: 151.8° H x 134.4° V
• Illuminance: 280 lux @ 5 m
• Control Protocols: DMX, RDM
• DMX Channels: 1–33 (11 modes total)
• Input Voltage: 100–240V AC, 50/60Hz (auto-ranging)
• Power Consumption: 345W @ 120V
• Power Linking: Up to 4 units @ 120V
• IP Rating: IP20 (indoor use only)
• Dimensions: 47.13 x 6.30 x 4.33 in (1197 x 160 x 110 mm)
• Weight: 24.6 lb (11.2 kg)

What's In The Box

• Ovation CYC 3 FC fixture
• Seetronic Powerkon power cable
• Omega brackets with mounting hardware
