Dual AES50 Output Stagebox

The Midas MDS-DL231 is a high-end digital stagebox offering 24 electronically balanced outputs with advanced AES50 networking and redundancy features. Ideal for large-scale productions and mission-critical live sound environments, it supports dual redundant AES50 ports and remote operation up to 100 meters over standard CAT5/5e cabling.

Midas MDS-DL231 Competitive Differences

Dual redundant AES50 ports for fail-safe audio networking
24 output channels routable from mic preamps or AES50 inputs

Midas MDS-DL231 Description

The MDS-DL231 delivers flexible and reliable stage connectivity for modern digital audio systems. With 24 electronically balanced output channels, it allows routing from either onboard microphone preamps or external AES50 network sources. Dual redundant AES50 ports with independent phase-locked loop (PLL) synchronization ensure stable and continuous audio transmission—even in critical situations. Selectable operation at 48kHz or 96kHz sample rates provides compatibility across a wide range of professional digital audio workflows. The DL231 is capable of remote operation up to 100 meters away via standard CAT5/5e cable, making it ideal for front-of-house, stage rack, or broadcast applications. Built into a robust rackmount chassis, the MDS-DL231 is engineered for the demands of touring, fixed installations, and broadcast production.

Model Features

24 electronically balanced output channels
Dual AES50 network ports with redundancy and independent PLL sync
Remote operation up to 100m over CAT5/5e
Selectable 48kHz or 96kHz sample rate operation
Rackmount form factor for live and installed use

Model Specifications

Outputs: 24 electronically balanced line level
Networking: Dual redundant AES50 ports
Sample Rates: Selectable 48kHz / 96kHz
Remote Range: Up to 100m via CAT5/5e
Dimensions: 48.26 x 41.33 x 22.15 cm
Weight: 14.8 kg (32.6 lb)

What's In The Box

Midas MDS-DL231 stagebox
Rack ears (pre-installed or included)
Power cable
