Pangolin Unity ELITE 60 PRO FB4 IP65 | 60W Full-Color RGB Laser | DMX, ArtNet & IP65 Outdoor Housing

Outdoor RGB Laser Projector

Pangolin Unity ELITE 60 PRO FB4 (IP65) is a high-powered, full-color laser projector designed for professional lighting designers, SFX teams, and large-scale event production. With a guaranteed output of over 59.5 watts and IP65-rated waterproof housing, this system excels in stadiums, arenas, and massive outdoor installations.

Pangolin Unity ELITE 60 PRO FB4 (IP65) Competitive Differences

• Over 59.5W Full-Color RGB Laser Output
• IP65-Rated Housing for Outdoor & Touring Use

Pangolin Unity ELITE 60 PRO FB4 (IP65) Description

The Unity ELITE 60 PRO FB4 (IP65) is a top-tier laser system featuring analog-modulated RGB laser diodes with a sharp <1.2mrad beam divergence and high scan accuracy. Built for professionals, it integrates the powerful Pangolin FB4 control interface, supporting Ethernet, ArtNet, sACN, DMX, auto-play, and mobile app control. Designed with precision and durability in mind, the IP65-rated aluminum enclosure ensures performance in challenging outdoor environments. This makes it ideal for festivals, stadiums, and high-impact installations where reliability is non-negotiable. Its robust system includes onboard configuration options for color balancing, positioning, safety, and system diagnostics, all managed via the FB4 interface. The package also includes a complete professional touring kit with rugged accessories, interlocks, and cables. From advanced mapping and graphic work to full-beam effects in massive venues, the Unity ELITE 60 PRO FB4 delivers powerful results with maximum flexibility.

Model Features

• Analog RGB diode laser system
• FB4 media server for multi-protocol control (DMX, ArtNet, sACN, Auto Mode)
• Waterproof IP65-rated housing for outdoor use
• Full digital control of all system parameters via FB4
• Beam size: 7 x 7 mm with <1.2 mrad divergence
• Integrated safety systems including keyed interlock, shutter, and scan-fail protection

Model Specifications

• Max Output Power: >59.5W RGB
• Red: 19,500mW | Green: 20,000mW | Blue: 20,000mW
• Beam Divergence: <1.2mrad (full angle)
• Scan Speed: 30,000pps @ 8°
• Scan Angle: 45°
• Control: FB4 (Ethernet, ArtNet, DMX, sACN, Auto, Mobile App)
• Ingress Protection: IP65
• Power Consumption: Max 1200W
• Power Input: 100–240V, 50Hz
• Operating Temperature: -10°C to 45°C
• Dimensions: 509 x 455 x 226 mm
• Weight: 32 kg

What's In The Box

• Unity ELITE 60 PRO FB4 Laser Projector (IP65)
• Protective Touring Case
• FB4 DMX Media Server (Pre-installed)
• Estop Box & 10M (30ft) Cable
• Ethernet Cable (10M / 30ft)
• Power Cable (1.5M / 4.5ft)
• Keys & Interlock Components
• Outdoor RJ45 Connectors
• Quick Start Guide & Manual
• Variance Card
