RCF NXL 44A MK2 | 3x10in - 135dB | 2100W Column Line Array Speaker, BMC & FiRPHASE

Column Line Array Speaker

RCF NXL 44A MK2 is a high-output active line array column speaker designed for touring, portable PA systems, and fixed installations. Its 3x10” woofer configuration, wide 100° x 25° dispersion, and built-in DSP make it ideal for medium-sized concerts, DJs, and AV rental setups that demand power, clarity, and control.

RCF NXL 44A MK2 Competitive Differences

• Delivers up to 135dB SPL with 2100W peak power
• Includes FiRPHASE and Bass Motion Control DSP for ultra-clean sound

RCF NXL 44A MK2 Description

The RCF NXL 44A MK2 is a two-way active line array column speaker, engineered to deliver outstanding audio fidelity and punch in a portable or installable format. Its compact yet powerful design features three high-efficiency 10” neodymium woofers and a 3” titanium compression driver, offering full-range response down to 45Hz. RCF's proprietary DSP includes FiRPHASE filtering for phase-coherent sound and Bass Motion Control (BMC), which enhances low-end clarity by managing woofer excursion without altering phase response. This combination allows the NXL 44A MK2 to maintain tight, clean bass and intelligibility at high SPLs. With a 100° x 25° constant directivity waveguide, the NXL 44A MK2 ensures wide horizontal coverage and focused vertical dispersion, reducing reflections and improving clarity in reverberant spaces. The onboard 2100W Class-D amplifier offers fast transient response, thermal protection, and fanless convection cooling for reliability in demanding environments. The rugged Baltic birch enclosure features integrated rigging points, PowerCON TRUE1 TOP connectors, and ergonomic side handles, making it suitable for ground stack, pole mount, flown, or coupled configurations. Whether for DJs, bands, or rental setups, this speaker delivers powerful and precise sound in a compact footprint.

Model Features

• Three 10" neodymium woofers for deep, punchy bass
• 3" titanium compression driver with neodymium magnet
• 100° x 25° coverage with constant directivity waveguide
• FiRPHASE and Bass Motion Control DSP processing
• 2100W Class-D amplifier with no fan required
• 8x M8 and 8x Quick Lock rigging points
• Balanced XLR/jack input and XLR output

Model Specifications

• Max SPL: 135dB
• Power Output: 2100W Peak (1400W LF / 700W HF)
• Frequency Response: 45Hz – 20kHz
• Coverage: 100° horizontal x 25° vertical
• Dimensions: 42.52 x 11.71 x 14.69 in (1080 x 297.5 x 373 mm)
• Weight: 73.63 lb (33.4 kg)
• UPC (115V): 8024530019853
• UPC (220–240V): 8024530019860

What's In The Box

• RCF NXL 44A MK2 speaker
• PowerCON TRUE1 TOP power cable
• Quick start guide
