RCF NXW 44A MK2 | 3x10in - 135dB | 100°x50° Column Speaker with FiRPHASE & BMC

Column Line Array Speaker

RCF NXW 44A MK2 is a high-performance active column speaker built for touring professionals, mobile DJs, and fixed installs. With a wide 100° x 50° dispersion and extended frequency response down to 45Hz, it offers clear, full-range audio with superior directivity control in a compact, road-ready format.

RCF NXW 44A MK2 Competitive Differences

• 100° x 50° wide coverage with Constant Directivity CMD horn
• Advanced DSP with FiRPHASE and Bass Motion Control

RCF NXW 44A MK2 Description

The RCF NXW 44A MK2 is a powerful two-way column speaker designed to handle demanding live sound and installation environments. It features three high-efficiency 10" neodymium woofers and a 3” titanium compression driver, optimized with a CMD (Constant Matching Design) horn for precise sound dispersion without tilting the enclosure. With a 2100W Class-D amplifier onboard, the speaker delivers up to 135dB SPL and handles extreme dynamic content with ease. Integrated DSP processing includes RCF’s proprietary FiRPHASE filtering and Bass Motion Control (BMC), which ensures phase-aligned sound and low-end clarity by controlling woofer excursion without sacrificing frequency response. The NXW 44A MK2’s 100° x 50° coverage makes it ideal for medium-size concerts, mobile DJ setups, clubs, and AV rental fleets. The robust Baltic birch enclosure features ergonomic side handles, PowerCON TRUE1 TOP connectors, and integrated rigging hardware for flown or ground-stacked configurations. For applications requiring extended low-end response, pairing with an RCF subwoofer delivers full-range performance in a compact, portable footprint.

Model Features

• 3 x 10" high-power neodymium woofers
• 3" titanium compression driver with CMD horn
• 100° x 50° constant directivity dispersion
• 2100W Class-D amplifier (700W HF / 1400W LF)
• Advanced DSP with FiRPHASE and Bass Motion Control
• Fanless convection cooling via aluminum heat sink
• Balanced XLR/jack combo input, XLR output
• 8x M8 and 8x Quick Lock rigging points

Model Specifications

• Max SPL: 135dB
• Power Output: 2100W Peak
• Frequency Response: 45Hz – 20kHz
• Coverage: 100° horizontal x 50° vertical
• Dimensions: 42.52 x 11.71 x 14.69 in (1080 x 297.5 x 373 mm)
• Weight: 69.56 lb (31.55 kg)
• UPC (100–120V): 8024530020507
• UPC (220–240V): 8024530020439

What's In The Box

• RCF NXW 44A MK2 speaker
• PowerCON TRUE1 TOP cable
• Quick start guide
