Remote Input PCB for Fog Machines

Smoke Factory SF-39004 is the dedicated remote-control printed circuit board for select Smoke Factory fog machines. This board provides the interface for external control methods such as DMX 512, analog 0-10 V remote control (cable or fader), and ensures proper signal processing and control feed-through for the mainboard.

Smoke Factory SF-39004 Competitive Differences

• Official OEM remote-control PCB — designed specifically for Smoke Factory models supporting DMX and analog remote inputs (e.g. TC4 / Data II / Captain D / others)
• Supports DMX 512 and analog 3-pin remote/fader control — preserves full compatibility with original control schemes and ensures stable, factory-spec remote operation

Smoke Factory SF-39004 Description

The SF-39004 PCB handles all external control wiring for Smoke Factory fog machines — converting incoming DMX or analog remote signals into commands the mainboard understands (pump activation, fog output percentage, timer, etc.). According to the official service manual for models like Enterprise TC4, the 39004 board is labeled “PCB Remote (DMX and analogue)” and is separate from the main power/control board.

If a fog machine loses remote or DMX control responsiveness — for example, no reaction to DMX commands, analog fader not affecting output, or erratic control — replacing the SF-39004 often restores proper remote control functionality. Because this is a genuine OEM part, compatibility with factory wiring harnesses and firmware logic is guaranteed, reducing risk compared to generic or aftermarket remote-controller boards.

This PCB is valuable for rental houses, touring rigs, stage installations, or any setup where remote/DMX control is critical and reliability under repeated use matters.

Model Features

• Remote-control PCB for DMX 512 input/output and analog remote/fader input 0-10 V
• OEM replacement — exact fit with Smoke Factory machines that originally shipped with DMX/analog remote capability
• Interfaces cleanly with mainboard — ensures signal integrity and proper control logic
• Ideal for restoring remote/DMX control on aging or malfunctioning machines

Model Specifications

• Part Number: SF-39004
• Function: Remote-control PCB (DMX & analog) — external control interface
• Compatible With: Smoke Factory fog machines with DMX / analog remote options (e.g. TC4, Data II, Captain D)

What’s In The Box

• PCB assembly SF-39004
• Mounting hardware / screws (as per original machine configuration)
• Connector headers / XLR / analog input interface (as per factory wiring harnesses)
